Mini Rice Corn Color Sorter Portable 99.9% Accuracy
Product Details:
| Place of Origin: | Anhui China |
| Brand Name: | DREAM PLUS |
| Certification: | CE、SGS、ISO9001 |
| Model Number: | 6SXM-160JM2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $12,300 |
| Packaging Details: | Wooden Packaging |
| Delivery Time: | 7-15 Work Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50 Set/Sets per Month |
|
Detail Information |
|||
| Capacity: | 500-1000 Kg | Accuracy: | 99.9% |
|---|---|---|---|
| Power: | 1.8 Kw | Voltage: | AC220V, 50Hz |
| Weight: | 600 Kg | Dimension: | 1330*1630*1550 Mm |
| Highlight: | Mini Corn Color Sorter,Corn Color Sorter Portable,99.9% Accuracy Corn Color Sorter |
||
Product Description
Mini Rice Corn Color Sorter Portable Rice Grader Machine
When color sorter is working, feed hopper in the materials under the action of vibrator is uniform distribution in each chute. The CCD signal while the materials are dropping is in testing. If it is found that there are unqualified materials or impurities in the materials, the ejector will blow the defective goods in the hopper.
Product Parameters
| Model | Capacity(T/h) | Power(Kw) | Voltage | Weight(Kgs) | Dimension(mm) |
|---|---|---|---|---|---|
| 6SXM-64J1 | 0.3-0.5 | 1.5 | AC220V/50Hz | 350 | 955*1630*1550 |
| 6SXM-80J1 | 0.3-0.6 | 1.65 | AC220V/50Hz | 500 | 1045*1630*1550 |
| 6SXM-96JM1 | 0.4-0.8 | 1.7 | AC220V/50Hz | 500 | 1045*1630*1550 |
| 6SXM-160JM2 | 0.5-1.0 | 1.8 | AC220V/50Hz | 600 | 1330*1630*1550 |
| 6SXM-192JM3 | 0.6-1.2 | 2.0 | AC220V/50Hz | 900 | 1530*1620*2040 |
| 6SXM-256JM4 | 0.8-1.5 | 2.6 | AC220V/50Hz | 1200 | 1800*1620*2040 |
| 6SXM-320JM5 | 1.0-2.0 | 3.0 | AC220V/50Hz | 1350 | 2190*1620*2040 |
| 6SXM-384JM6 | 2.0-3.0 | 3.6 | AC220V/50Hz | 1500 | 2528*1620*2040 |
| 6SXM-448JM7 | 3.0-4.0 | 4.0 | AC220V/50Hz | 1750 | 2765*1620*2040 |
| 6SXM-512JM8 | 4.0-5.0 | 4.6 | AC220V/50Hz | 1800 | 3152*1620*2040 |
| 6SXM-640JM10 | 5.0-6.0 | 5.5 | AC220V/50Hz | 2200 | 3910*1620*2040 |
Sorting Material
Features
Micron camera
High resolution ultra-low distortion micro camera imaging system,with electrodeless LED light source, brings unprecedented precision recognition.
Full core upgrade
Intel fifth generation FPGA has the advantages of faster processing speed, lower power consumption and more stable system operation.
5G Architecture
Reserved 5g interface, AR / VR coordination, high bandwidth,low delay, wide connection.
Intelligent dimming
Digital stepless dimming, automatically matching brightness according to material change.
Intelligent magnetic control high frequency solenoid valve
High frequency low consumption valve, flexible contact,wear-resistant super alloy material, life-long matching use.
Human-computer interaction
Automatic acquisition of temperature, humidity, air pressure,differential pressure and other related working environment,parameters to achieve monitoring and early warning.
Intelligent operation system
Firstly applied Windows 7 operating system in color sorter industrycan beupgraded to Windows 8 and Windows 10 according to different application.
High speed feeding system
Patented high-frequency vibrator and antioxidant anode treatment chute greatly increased production by 20% ~ 30%compared with other competitors.
Machine Working at Site
